66960 Air Compressor 3500 PSI Diesel Driven 2MC1A High Pressure

Davey 2MC1A High Pressure Air Compressor Unit
66960
Air Compressor Unit-
Specification: MIL-C-9001
Type: Reciprocating
Air Volume: 15 scfm (0.43 m3/s)
Air Pressure (MAX): 3500 PSIG
Power Source: Diesel Engine
Operating Temperature Range: -65 deg to 125 deg f (-32 deg to 52 deg c)
Mounting: 4 Wheel Trailer with pneumatic tires
Brakes: Mechanical Hand Brake
Tire Size: 6:00 x 9, (152.4 x 288.6 mm) 6 Ply
Tire Pressure: 30 psig (206.9 Kpa)
Turning Radius: 14 feet @ ten mph (170 m @ 16 Km/h)
Towing Speed: Improved Surface 25 mph (40 Km/h)
Unimproved Surface: 10 mph (16 km/h)
Electrical System: 12 vdc, neg. gnd.
Length (OA): Towbar Down: 119-1/2 in. (3035.3 mm)
Towbar Up: 81-1/2 in. (2070.1 mm)
Width (OA): 66-3/4in. (1695.55 mm)
Height (OA): Towbar Down: 55-3/8in. (1406.5mm)
Towbar Up: 60 in. (1524 mm)
Volume: 193 cu ft (5.78 m3)
Weight (dry): 2100 lbs (952.6 kg.)
Air Compressor Assembly-
Specification: MIL-C-26805
Type: 4 Stage, radial, reciprocating
Number of cylinders: 4
Cooling: Forced Air
Operating Temperature Range: -65 deg to 125 deg f (-32 to 52 deg c)
Diesel Engine Assembly-
Specification: MIL-STD-1410
Type: 4 Stroke-cycle, reciprocating
Number of Cylinders: 2
Bore and stroke: 3.54 in (90 mm) x 3.94 in (100 mm)
Displacement: 77.5 cu in. (1.27 ltr)
Governed Speed: 2000 rpm (2000 r/m)
Horsepower: 18.4 @ 2000 rpm, SAE (18.6 @ 2000 r/min, DIN)
Combustion Method: Direct Injection
Cooling: Forced Air
Compression Ratio: 18:1
Operating Temperature Range: 0f (-18c) to +125f (+52c)
Engine Accessories-
Starting Motor: 12vdc
Alternator: 13.5 amp, 12vdc, negative ground
Fuel: Military Specification -J-5624 or Federal Specification VV-F-800
Clutch Assembly-
Type: Dry, single plate, manually operated
Capacities-
Fuel Tank: 16-3/4 gallons (62 ltr)
Engine Lubricating Oil: With Filter Change- 4.3 quarts (4 ltr)
Without filter change- 3.2 quarts (3 ltr)
Compressor Lubricating Oil: With Filter Change- 5 quarts (4.7 ltr)
Without Filter Change- 4 quarts (3.8 ltr)
Air Receiver- 500 cu in. (8.2 ltr)
USED AND BEING SOLD, "AS IS".
Freight quote available. Please message us for inquires.
Domestic shipping only.
We do have parts and manuals in stock for this machine.
